Cell Level Electro Thermal Discretization
Resolve current and temperature at the cell level to analyze thermal gradients, spot hotspots, and optimize design before prototyping.
Solutions
Battery Thermal Management
GT-SUITE provides the ideal platform for optimizing battery thermal management systems
Solution Overview
Integrated Electro-Thermal Modeling
In GT-SUITE batteries are optimized on the cell, module, and pack level. The temperature and current distribution within the cells and pack are simulated to predict the battery performance under a variety of dynamic conditions.
These battery models are integrated with the electrical system and coolant system to capture the transient effects on battery performance, heat generation rate, vehicle range, and more.
Application Highlights
Accelerate Battery Thermal Analysis
- Integrate battery thermal model with electrical and fluid systems
- Use well-established 3D-CAD based process to create high-fidelity component models
- 1D flow +3D FE thermal models built using GEM3D, which are unique to G-SUITE, can provide accurate pressure drop and temperature distribution much faster than 3D CFD
- Quickly size cooling plate geometry
- Easily review results for both steady-state and transient conditions
Advanced Battery Thermal Modeling Capabilities
Simulate battery temperature, current distribution, and thermal performance across cells, modules, and packs within an integrated electro-thermal environment.
Multi Technique Cooling Strategy Evaluation
Simulate and compare direct liquid, indirect liquid, air, and two phase refrigerant cooling to find the optimal thermal strategy for your pack.
Full Pack and Cell Level Temperature Prediction
Predict thermal gradients from cell to full pack under dynamic conditions using GT-SUITE's integrated 1D flow and 3D FE models, faster than traditional 3D CFD.
Thermal Runaway Propagation Prediction
Simulate thermal runaway onset and propagation across the pack to assess safety risks, evaluate mitigation strategies, and support regulatory compliance.
Transient Environmental Performance Analysis
Evaluate battery behavior across environmental conditions, including cold start warm up and high temperature cool down, to ensure reliable real world performance.
Integrated Electrochemical and 3D CFD Coupling
Extend thermal models with GT-AutoLion for electrochemical aging and state of health prediction, or GT-CONVERGE 3D CFD for detailed flow thermal analysis, all in one environment.
Battery Thermal Management FAQs
Find answers to common battery thermal modeling and simulation questions.
-
Can GT-SUITE simulate the full battery thermal system — cells, modules, and pack — in a single environment?
Yes. GT-SUITE models battery thermal behavior at the cell, module, and pack level all within the same simulation, while integrating that thermal model with the electrical and coolant systems. This means engineers can capture transient interactions like heat generation and temperature distribution, and see how those factors affect vehicle range, all without switching between separate tools.
-
How does GT-SUITE handle battery cooling strategy evaluation without running expensive 3D CFD simulations for every design variant?
GT-SUITE combines 1D flow modeling with 3D finite element thermal analysis through its GEM3D tool. This hybrid approach delivers accurate pressure drop and temperature distribution results in a fraction of the time it would take using full 3D CFD. As a result, engineers can compare cooling topologies such as immersion cooling, cold plates, air cooling, or two-phase refrigerant systems, and land on the best configuration early in development, without the computational cost of running CFD on every variant.
-
Can GT-SUITE predict thermal runaway propagation across a battery pack?
Yes. GT-SUITE includes purpose-built capabilities for predicting how thermal runaway propagates through a battery pack, which supports both safety validation and regulatory compliance work. Engineers can use these models to test and refine design decisions that reduce propagation risk long before a physical prototype exists.
-
Does GT-SUITE support electrochemical battery modeling, and how does it connect to system-level thermal simulation?
Yes, through an optional link to GT-AutoLion, which provides physics-based electrochemical cell modeling. This connection lets engineers predict aging, state of health, and how heat generation is distributed spatially within the cell. It also means system-level thermal and energy management decisions can be based on real cell-level electrochemistry rather than relying on simplified lookup tables or empirical assumptions.
